Ashlar Argon (8003)
Price: $1,29500
Ashlar Argon (8003)
  2. Save to wishlist

Ashlar Argon (8003)

Item#:  7531341  | Model#: 8003
Temporarily out of stock. Order today and we'll deliver when available. (Details)

Ashlar Argon (8003) Product Details

Argon v8.0
History-free precision modeling.

Argon offers entry-level 3D modeling without the commitment of high-end professional packages. It contains the same solid and surface modeling, rendering engine and animation tools found in Cobalt and Xenon, but without the high-end mechanical design and extreme productivity features you may not need—yet. For both Macintosh and Windows, Argon lets you model and render with such a straightforward interface that you’ll forget you’re using a computer. Intended for those needing precision 3D modeling without cumbersome parametric history,

  • Updated Interface
  • Unified Drawing & Modeling Tools for Wireframe, Surfaces & Solids
  • Vellum Drafting AssistantTM for Intelligent Snaps and Alignments in X,Y, & Z
  • Unique Hybrid Mac/Windows, Office/Home Licensing
  • Class-A NURBS Surface Modeling
  • True Solid Modeling
  • Surface Analysis
  • 2D Drawing Snapshots
  • Complete Set of Precision Import/Export Translators Including ACIS SAT, Parasolid, IGES, STEP, DXF, DWG, EPS, AI, and more
  • Support for Intel Mac
  • Full Photo-realistic Rendering & Camera-based Animation
  • Object and Group Properties (CG, Volume, Weight, etc.)

General Features

  • Direct 3D Modeling
  • ACIS Modeling Kernel from Spatial
  • 16 Place Floating Point Accuracy
  • Hybrid Mac/Windows, Office/Home License
  • 65,000 Hierarchical Layers
  • Unlimited Colors
  • Unlimited Number of Objects and Drawing Size
  • Single File Holds Drawings, Models, Assemblies, etc.
  • Direct Multi-sheet PDF Creation
  • Universal Binary Support for Intel Mac

User Interface

  • Updated Intuitive Vellum Interface
  • Drafting AssistantTM for Automatic Snaps and Alignments
  • Smart Cursor Changes Shape Indicating Active Tool and Operations
  • Strokes and Short Cuts Provide Instant Access to Commands
  • Tear-off and Auto-hide Palettes
  • Dockable Tools and Palettes
  • Palettes can be Flipped Vertically or Horizontally
  • Resizable Dialog Boxes
  • Status Line to Specify Object Parameters
  • Message Line Provides Tool Instructions and Options
  • World and User-defined Coordinate Systems
  • All Data Entry Fields can Perform Numeric Calculations
  • TrackBall for View Selection and Dynamic or Step Rotation
  • Show/Hide Palette
  • Selection Mask for Easier Selection of Specific Entity Types, Layers, Colors
  • Grid (User Definable)
  • Object Editor
  • Support for SpaceMouse Device on Mac and Windows
  • Easy Update Installer

Recommended System
• Windows / Macintosh
• Windows XP/Vista
• Mac OS X 10.4 (PPC) 10.5 (PPC or Intel)
• Pentium 4, Xeon, Athlon / G4 or G5
• 32 MB Accelerated Video Card w/ Open GL (Standard on all business-class systems since 2005. Additional RAM will not improve performance.)
• Medium- to High-performance Workstation Graphics Subsystem Recommended for Real-time Environment Mapping on Complex Files
• 512 MB RAM
• 250 MB Free Hard DriveSpace / 1 GB Allocated Virtual Memory
• DVD Drive or High Speed Internet Connection
  • Manufactured by: Ashlar
    UPC No:
    Mfg Part No: 8003
  • Box Size: ( Length:0, Width:0, Depth:0)
    Shipping Weight: 1.2000 pound(s)
