400W P2U REDUNDANT POWER SUPPLY
Price: $31000
ADD TO CART
400W P2U REDUNDANT POWER SUPPLY
  1. ADD TO CART
  2. Save to wishlist

DynaPower USA 400W P2U REDUNDANT POWER SUPPLY (DP-400R2U)

Item#:  7284554  | Model#: DP-400R2U
Price:
$310.00
Shipping:
Temporarily out of stock. Order today and we'll deliver when available. (Details)

400W P2U REDUNDANT POWER SUPPLY Product Details

400W 2U Redundant


Professional Power supply …… Industrial PC, Server, Storage


AC Input:

  • VOLTAGE:  100 - 240V(Active PFC/Full Range)
  • FREQUENCY:  47 - 63Hz
  • POWER FACTOR CORRECTION:  0.95
  • INPUT CURRENT:  8A/4A For 115/230VAC
  • INRUSH CURRENT:  60A/80A MAX FOR 115/230

Features:

  • TEMPERATURE RANGE: Operation 0C - 50C

  • HOLD UP TIME: 16ms at maximum load & normal input voltage

  • EFFICIENCY: 70% TYPICAL (Normal Line)

  • POWER GOOD SIGNAL: Should be asserted high to indicate that+5VDC and +3.3VDC output are above the low voltage thresholds. Compatible signal out with 100ms to 500ms.

  • OVER POWER PROTECTION: The power supply shall shout down output power exceeds 130% to 160%

  • OVER VOLTAGE PROTECTION: +5V, +3.3V and +12V DC outputs set at 110%-130%

  • EMI: FCC part 15, subpart B, Class B, EN55022 CISPR22 Class B.
  • SHORT CIRCUIT PROTECTION: A short circuit placed between the DC return and the output shall cause no damage and the power supply shall shutdown.

  • Meet EN-61000-3-2 CLASS D ( Active PFC )

  • GAENCY APPROVALS: UL60950, CAN/CSA22.2 No.60950, TUV(IEC60950)

  • MTBF OF POWER SUPPLY

  • ELECTRONNIS: 100,000 hours at 25C.

  • LIFE EXPCTANCY OF FAN 40,000 hours at 40C

  • COLLING: By forced air 1x40mm Fan (Each module)

  • Manufactured by: DynaPower USA
    UPC No:
    Mfg Part No: DP-400R2U
  • Box Size: ( Length:0, Width:0, Depth:0)
    Shipping Weight: 15.0000 pound(s)
    Click here for full warranty and support information
  • DynaPower USA logos are registered trademarks of DynaPower USA. All others trademarks and copyrights mentioned herein are the property of their respective owners.
